Heater problems usually do not begin at the time of heater malfunction. Heater problems begin from the very first day of installation.
The heater may pass the initial test run, maintain the temperature for many weeks, and remain a ticking time bomb. The bore may have been slightly oversized, the terminal may have been improperly tightened, or the duct heater may have been installed at a place of easy mounting instead of the optimal location. This does not manifest itself immediately. It does show up later, often not at a convenient time.
If the root cause of the problem lies in the installation, why replace the heater repeatedly?
Maintenance can prolong the life of the heater, but it will not eliminate the installation error. The heater manufacturer defines the tolerance, ratings, and clearance specifications that all industrial heater installations must adhere to.
Three installation errors deserve the closest attention, because each one quietly shortens heater life. Knowing them is the first step to avoiding them, along with many other common industrial heater issues.
A heater can only deliver the heat it can transfer. When it doesn’t sit tight against the surface it’s meant to heat, that transfer drops.
Cartridge heaters show this clearly. They sit in machined bores in moulds, dies and tooling blocks, pushing heat into the surrounding metal. Leave too much clearance and the gap fills with air, which is a poor conductor. The metal runs cooler than it should. The heater, with nowhere to send its heat, runs hotter, sometimes well past its designed operating range.
The fix starts before the heater goes in. Bore size and heater diameter must match the specified tolerances, and the bore should be clean and free of damage. Band heaters work on the same principle: correct sizing, firm clamping and full contact with the barrel.
There are times when the failure is not in the element but in the terminal. The heating element can be properly engineered and properly installed.
A poor or improper connection increases the resistance at the point where the connection is made. With each flow of electric current, heat builds up at that point. This goes on week after week, until eventually the heat damages the terminal component and causes a heating problem.
Connections must be made following the manufacturer’s instructions. The wires used must also have the proper capacity and insulation for the heater’s current and temperature requirements. Bends should never be sharp where the wire leaves the heater.
“Many of the failed heaters we’re asked to look at were sound when they left our facility. The bore was loose, a terminal wasn’t tight, or nobody checked the airflow. A few minutes of checking at installation would have saved a replacement and a lost shift.” Technical Head, DHE Heaters
Open-coil and duct heaters depend on moving air to carry heat away from their elements. Starve them of airflow, and the elements overheat.
Placement is where this usually goes wrong. A duct heater installed too close to a bend, damper or other obstruction sees uneven airflow across its bank. Some elements get plenty of cooling. Others get very little, and those are the ones that develop hot spots, trip protective shutdowns or fail early.
Positioning, airflow and clearances should follow the manufacturer’s requirements to the letter. An airflow interlock adds a second line of defence, keeping the heater switched off until airflow is confirmed.
Five checks, completed before the heater is switched on for the first time, catch these problems while they’re still cheap to fix.
These checks belong at the integration stage, not after the first breakdown.
A new installation, or a heater that keeps failing, deserves a second pair of eyes before it goes live. Share your application details with DHE’s engineers for a pre-commissioning review that catches fit, electrical and airflow problems before they turn expensive.
A heater that’s installed right tends to stay out of the maintenance log. Fit, connections, airflow, and controls are settled before commissioning instead of being fixed after the first unplanned stop.
The right heater, installed to the right specification, pays for itself in uptime. Talk to DHE’s team about your application and the conditions your equipment runs in.
